Detailed description

X travel:630 mm

Y travel:630 mm

Z travel:630 mm

Spinle center to table surface:50~680 mm

Spinle nose to table surface:130~760 mm

CNC Control:Fanuc/Mitsubishi/Siemens

Table able surface to floor:1,100 mm

Table size:400×400 mm

T-SLOT/BOLT spec.:24-M10 x P1.5 x 20

Table load capacity:400kgs

Index precision:0.001°

Spindle transmission:Direct type

Spindle taper:BT-40

Spindle Speed:10,000 rpm

ATC Capcity:40 tools

APC number of pallets:2 pcs

APC method of pallet change:Rotary type

APC pallet change time:8 sec

X TRAVEL:800 mm/31.5 inch
Y TRAVEL:725 mm/28.54 inch
Z TRAVEL:725 mm/28.54 inch

HM-500
X TRAVEL:1,000 mm/39.37 inch
Y TRAVEL:850 mm/33.47 inch
Z TRAVEL:950 mm/37.4 inch

HM-630
