Horizontal Lathe
Linear Way
-
![]()
X axis travel :17.28+0.59 inch
Z axis travel :15.75 inch
-
![]()
X axis travel :7.28+0.59 inch
Z axis travel :23.62 inch
-
![]()
X axis travel :7.09+1.38 inch
Z axis travel :19.69 inch
-
![]()
X axis travel :6.3+1.18 inch
Z axis travel :14.17 inch
-
![]()
X axis travel :8.27+0.79 inch
Z axis travel :23.62 inch
-
![]()
X axis travel :12.21+1.18 inch
Z axis travel :45.28 inch
Box Way
-
![]()
X axis travel :8.07+0.99 inch
Z axis travel :21.65/31.5/41.34 inch
-
![]()
X axis travel :8.07+0.99 inch
Z axis travel :21.65/31.5/41.34 inch
-
![]()
X axis travel :7.09+0.59 inch
Z axis travel :12.99 inch
-
![]()
X axis travel :6.3+1.18 inch
Z axis travel :14.17 inch
-
![]()
X axis travel :8.27+0.79 inch
Z axis travel :23.62 inch
-
![]()
X axis travel:8.27+0.79 inch
Z axis travel:23.62 inch
-
![]()
X axis travel :12.21+1.18 inch
Z axis travel :45.28 inch
